Prozessor: |
AMD FX-8120 |
|
| Codename: | Zambezi |
| Architekt.: | 1 CPU - 8 Kerne - 8 Threads |
| Revision: | OR-B2 |
| Tech.: | 0.0320 µ |
| F.M.S.: | F.1.2 - Ext. 15.1 |
| Instruct.: | MMX(+) SSE (1 2 3 3S 4.1 4.2 4A) x86-64 AMD-V AES AVX XOP |
| Socket: | Socket AM3+ (942) |
| CPU-Takt: | 24/7= 4415.37MHz (4916.23 MHz OC) |
| Multiplik.: | 24/7= 22 (x24.50 OC) |
| FSB: | 200.66 MHz / Northbridge @ 2608,8MHz |
| L1 Cache: | Data: 4 x 64 / Inst: 8 x 16 KBytes |
| L2 Cache: | 4 x 2048 KBytes |
| L3 Cache: | 8192 KBytes |
| Voltage: | 24/7= 1,368 V (1,488 V OC) |
| Besonderh.: | Black, polierter Heatspreader |
| Overclocked: | 4916.23 MHz OC |
| Kühlung: | Watercool Heatkiller 3.0, Arctic MX-2 |
| Temperatur: | (Idle:29°C, Last 58°C OC) 24/7= 29°C , Last 47°C |
| CPU-Z Vers.: | 1.64
|
|
|
MainBoard: |
Crosshair V Formula-Z |
| Chipsatz: | AMD 990FX/SB950 |
| Northbridge: | AMD RD9x0 rev 02 |
| Southbridge: | AMD SB910/950 rev 40 |
| Revision: | 1.1 |
| BiosVersion: | 1403 |
| Anschlüsse: | 3 x PCIe 2.0 x16 (dual x16 or x16/x8/x8) 1 x PCIe 2.0 x16 (x4 mode) 2 x PCIe 2.0 x1 1 x USB 3.0 2 USB 3.0 ports 2 x USB 2.0 ports 4 USB 2.0 ports 1 x TPM connector 8 x SATA 6Gb/s 2 x CPU Fan 3 x Chassis Fan 3 x Optional Fan 1 x S/PDIF out 1 x 24-pin EATX Power 1 x 8-pin ATX 12V Power 1 x 4-pin ATX 12V Power 1 x Front panel audio (AAFP) 1 x System panel 1 x DirectKey Button 1 x DRCT header 8 x ProbeIt Measurement Points 3 x Thermal sensor 1 x EZ Plug 4-pin Molex power 1 x Power-on Button 1 x Reset Button 1 x Go Button |
| extern: | 1 x PS/2 keyboard/mouse combo port 2 x eSATA 6Gb/s 1 x LAN (RJ45) port 4 x USB 3.0 8 x USB 2.0 (1 port für ROG Connect) 1 x Optical S/PDIF out 6 x Audio jack 1 x Clear CMOS button 1 x ROG Connect On/ Off switch |
| Temperatur: | 34°C |
| Kühlung: | EK Water Blocks EK-FB ASUS C5F-Z
|
|
|
RAM: |
4096 MB Corsair (10700)
4096 MB Corsair (10700)
4096 MB Corsair (10700)
4096 MB Corsair (10700) |
| Size: | 16384 MB (4 x 4GB) |
| Typ: | DDR3-SDRAM Dual Channel |
| Timing: | 9.0-10-9-27 |
| RAM-Takt: | 936.5MHz |
| Voltage: | 1,50 V |
| Ratio: | 3:14 |
| Kühlung: | Luft |
|
Grafikkarte: |
AMD Radeon HD 7800 Series |
| Subvendor: | Powercolor ATI AIB |
| Chipsatz: | Tahiti |
| Tech.: | 28 nm |
| RAM: | 2048 MB GDDR5 |
| RAM-Takt: | 1600 MHz |
| Width: | 256 bit |
| Bandwith: | 192.0 GB/s |
| Core-Takt: | 1200 MHz (975 MHz) |
| Shaders: | 1536 (DX 11.1) |
| Shader-Takt: | 1200 MHz |
| Fillrate: | 35.2 GPixel/s | 105.6 GTexel/s |
| Bus: | PCI-E 3.0 x16 @ x16 1.1 |
| Anschlüsse: | DL-DVI-I/ HDMI/2x mini DisplayPort |
| Temperatur: | Idle: 31°C , Last:52°C |
| Kühlung: | Wasser |
| Treiber, Ver.: | 13.101.0.0 (Catalyst 13.6) / Win8 64 |
| GPU-Z Vers.: | GPU-Z 0.7.1
|
|
|
Sound: |
Asus Xonar Phoebus |
| Signalproz.: | C-Media CMI8888DHT High-Definition Sound Processor |
| Soundmodus: | Dolby® Technologies : Dolby® Home Theater v4 Smart Volume Normalizer™ Xear Surround™ Magic Voice™ FlexBass™ GX 3.0 Game Audio Engine |
| Eingänge: | 2 x 3.5mm RCA jack 1 x Digital S/PDIF Output : 1 x Toslink 1 x Box link Other line-level analog input (for CD-IN/TV Tuner) : 4-pin header on the card |
| Ausgänge: | 5 x 3.5mm RCA jack |
| Features: | Kontrollbox mit Headset-Anschluss, EMI-Abschirmung, TPA6120A2 Kopfhörer-Verstärker, PCM1796 Digital-Analog-Wandler
|
|
|
GehäuseTyp: |
Big-Tower - Window |
| Marke: | BitFenix Shinobi XL |
| Front: | 3 x 120mm Enermax |
| Heck: | 2 x 120mm Enermax |
| Oben: | 3 x 120mm Scythe |
| Netzteil: | Seasonic X- Series SS-850-KM |
| Leistung: | 850 W |
| Kühlung: | Seasonic Hybrid Silent Fan Control |
| Geräusch: | Semi-passiv |
| WirkGrad: | 80PLUS® Gold |
|
|
WaterCooling: |
Watercool, EKWB |
| Pumpe: | Aqua Computer D5 mit USB- und aquabus |
| Kühlkörper: | Heatkiller 3.0 / EK-VGA-SUPREMACY / EK-FB ASUS C5F-Z |
| Ausgl.Beh.: | Magiccool |
| Radiator: | 360 + 360 + 120 Magiccool |
| Schläuche: | 13/10 |
|
|
Monitor: |
|
Empfehlungen:
CPU
FB 7390
Prozessor: AMD FX-8120
Grafikkarte: AMD Radeon HD 7800 Series
Auflösung: Angabe fehlt.
Mainboard: Crosshair V Formula-Z
Treiber: 13.101.0.0 (Catalyst 13.6) / Win8 64
OS: Windows 8.1 Pro Preview mit Media Center
